Description

Bren-Tronics BTA-70396 (J-6354/P) and BTA-70834 (J-6358B/P) Adapter Terminals

The Bren-Tronics BTA-70396 (J-6354/P) and BTA-70834 (J-6358B/P) adapter terminals are used for charging one (1) or two (2) batteries and when used in conjunction with the appropriate battery charger will charge one (1) or two (2) batteries in 3 hours or less

BTA-70396 (J-6354/P) NSN: 5940-01-427-9278 and BTA-70834 (J-6358B/P) NSN: 5940-01-501-3312

Recommended Charger:

• • BTC-70801
  • BTC-70844
  • BTC-70819

Batteries Charged:

• • • BTA70396: BB-2847’s
    • BTA70834: BB-390’s, BB-590’s and BB-2590’s

Technical Data for BTA-70396 and BTA-70834:

• • Dimensions – Length: 3.5 in (89 mm) Width: 5.5 in (140 mm) Height: 1.9 in (48 mm)
  • Weight – 0.44 lbs. (0.20 Kg)
  • Storage Temperature – -40°C to +70°C (-40°F to +158°F)
  • Material / Color – Modified ABS Plastic / Olive Drab
